71
SIGNAL SYSTEM
The same bulb is used tor both oil level check light and turn signal indicator light.The circuitry is
shown below.When the oil level has fallen to a certain level (the remaining amount of oil has
become approximately 160 ml,the oil level check light turns on and remains lit.When the turn signal
switch is turned on and the turn signal light flashes,the turn signal indicator light (oil level check
light)also flashes,both being not concurrently but alternatively as one being lit white the other unit.
)LJ
OIL LEVEL SWITCH INSPECTION
Check the oil level switch for continuity between the lead wire.If the tester does not show the value
of 0-1 ohm when the switch ring is in bottom position,file the contact surface or replace the unit.
