78
LEGSHIELD
AND PEDAL
REMOV
AL
1. Remove power lock housing
ཱ
by unscrewing bolt
3.
remove legshield and pedal by
unscrewing the four bolts
ི
Legshield and pedal installation
4. the sequence of legshield and pedal is the reverse of reomval
᧷
ཱ
ི
