TIGHTENTING TORQUE O F SCREW THREAD PARTS
ENGINE
ITEM
N᧪M
Cylinder guide cover tapping screw 1-4
Fan guide cover lock bolt 10-12
Cylinder cover locknut 15-18
Spark plug 15-18
Inlet pipe lock bolt 10-12
Cooling fan impeller lock screw 10-12
Flywheel lock bolt 45-50
Magneto stator coil lock screw 10-12
Magneto exciting lock screw 3-5
Oil pump lock screw 5-9
Right crankcase lock bolt 10-12
Bearing press board lock bolt 10-12
Cylinder double head bolt 15-18
Motor tightening bolt 10-12
Left crankcase cover lock screw 10-12
Left crankcase cover lock bolt 10-12
Main drive wheel face locknut 35-38
Driven wheel face locknut 35-38
Driven wheel face clutch locknut 55-60
Exceeding clutch outside lock screw 10-12
Electrical start idle press board screw 10-12
Gearcase lock bolt 10-12
Left crankcase discharging oil hole lock bolt 22-25
Left crankcase positioning pin shaft locknut 18-22
