92
႒ remove disc brake system by unscrewing tightening bolt.
႒ remove handle by removing tightening bolt
႒ unscrew locknut with special tool
႒ remove fornt fork assy. by removing upper outer steel bowl
NOTE:
Not drop the steering stem balls.
႒ remove front fork
႒ remove bearing lower race by chisel.
႒ Remove steel balls.
Number of steel balls᧶
Upper᧶21
lower᧶21
႒ remove the upper and lower bearing inner races with a appropriate bar
