1 = LEDs 2= QSFP+ ports
Note
VIMs are not hot swappable. You must power down the switch before installing any VIMs.
Alternate Stacking for X460-G2 Switches
X460-G2 10-gigabit switch models (10GE4) support alternate stacking (SummitStack-V feature)
through the 10G SFP+ ports located on the front panel. See Summit X460-G2 (10G Models) Stack
Configuration Guidelines on page 156 for additional considerations.
X460-G2 1-gigabit switch models (GE4) support alternate stacking through an attached VIM-2x
module. See Summit X460-G2 (1G Models Using VIM Ports) Stack Configuration Guidelines on page 157
for additional considerations.
Note
40G ports on the VIM-2q cannot be partitioned into four 10G ports.
Table 66 summarizes alternate stacking support for X460-G2 switches.
When the stacking-support option is enabled (with the enable stacking-support command),
data communication stops on the physical data ports that are designated for alternate stacking. Then,
when stacking is enabled (with the enable stacking command), those ports – listed in the
Alternate Stacking Ports column of Table 66 – operate using the stacking protocol for the logical
stacking ports.
Table 66: Alternate Stacking Ports for X460-G2 Switches
Switch Model Type or location of Native
Stacking Ports
Alternate Stacking
Ports
Location of Alternate
Stacking Ports
X460-G2-24t-GE4
X460-G2-24p-GE4
VIM-2ss or VIM-2q 33,34 VIM-2x
X460-G2-48t-GE4
X460-G2-48p-GE4
VIM-2ss or VIM-2q 53,54 VIM-2x
X460-G2-24t-10GE4
X460-G2-24x-10GE4
X460-G2-24p-10GE4
VIM-2ss or VIM-2q 31,32 Front panel
X460-G2-48t-10GE4
X460-G2-48x-10GE4
X460-G2-48p-10GE4
VIM-2ss or VIM-2q 51,52 Front panel
Note
•
On X460-G2 24-port 10GE4 switches, ports 31 and 32 are not available as data ports when
the alternate stacking ports are used.
•
On X460-G2 48-port 10GE4 switches, ports 51 and 52 are not available as data ports when
the alternate stacking ports are used.
Building Stacks
ExtremeSwitching and Summit Switches: Hardware Installation Guide 155
