Figure 190: Fastening the STK-RPS-150CH2 to the Rack
1 = STK-RPS-150CH2 shelf
3 = Mounting screws
2 = Rails of rack
Figure 191: Fastening the STK-RPS-150CH8 to the Rack
1 = STK-RPS-150CH8 shelf
3 = Mounting screws
2 = Rails of rack
Installing External Power Supplies
