Table 308: RJ45 Console Port on Switch (continued)
Function Pin Number Direction
DSR (data set ready) 7 In
RTS (request to send) 8 Out
Table 309 shows the pinouts for an RJ45-to-DB-9 adapter.
Table 309: Pinouts for an RJ45 to DB-9 Adapter
Signal RJ45 Pin DB-9 Pin
CTS (clear to send) 1 8
DTR (data carrier detect) 2 6
TXD (transmit data) 3 2
GND (ground) 4 5
GND (ground) 5 5
RXD (receive data) 6 3
DSR (data set ready) 7 4
RTS (request to send) 8 7
Technical Specifications
ExtremeSwitching and Summit Switches: Hardware Installation Guide 395

Extreme Networks ExtremeSwitching X440-G2 Series Specifications

General

Form Factor	Rack-mountable
VLAN Support	Yes
Humidity	5% to 95% non-condensing
Model	X440-G2 Series
Port Type	Gigabit Ethernet
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
Stacking	Yes, up to 8 switches
Layer Support	Layer 2/3
Operating Temperature	0°C to 50°C
Product Type	Switch
Jumbo Frames	9216 bytes
AC Power Supply	100-240 VAC, 50-60 Hz
Storage Temperature	-40°C to 70°C
Port Configuration	24 or 48 ports
Power over Ethernet (PoE)	Optional
