Extron electronics MLC 226 Series User Manual

A-5MLC 226 MediaLink
™
Controllers • Reference Material
PRELIMINARY
Electrical boxes and mud rings Part number
EWB-3Gang three gang external wall box 60-454-0x
EWB-5Gang five gang external wall box 60-456-0x
EWB-10x8 external wall box 60-457-0x
SMB-3Gang three gang surface mount box (black) 60-641-02
SMB-5Gang five gang surface mount box (black) 60-643-02
SMB-7Gang seven gang surface mount box (black) 60-645-02
Three gang mounting bracket/mud ring (black) 70-086-12
Five gang mounting bracket/mud ring (black) 70-086-14
Control accessories Part number
IR Emitter 70-283-01
IR Emitter (dual) 70-283-02
IR Broadcaster 60-272-01
Current/display power sensor 60-271-01
IR Link IR signal repeater
(gray, black, white, RAL9010 white) 60-404-01, -02, -03, -05
IR 402 remote control (1) 70-207-01
SCP 226 (black, white, RAL9010 white) 60-671-01, -02, -03, -05
SCP 226 AAP (black, white, RAL9010 white) 60-671-12, -13, -15
SCP 226L (black, white, RAL9010 white) 60-671-32, -33, -35
MLA-VC10 volume controller 60-502-01
IRCM-VCR
(gray, black, white, RAL9010 white) 70-148-01, -02, -03, -05
IRCM-DVD
(gray, black, white, RAL9010 white) 70-149-01, -02, -03, -05
IRCM-DVD+
(gray, black, white, RAL9010 white) 70-179-01, -02, -03, -05
IRCM-Tape
(gray, black, white, RAL9010 white) 70-180-01, -02, -03, -05
IRCM-DV+
(gray, black, white, RAL9010 white) 70-220-01, -02, -03, -05
RCM-SC
(gray, black, white, RAL9010 white) 70-183-01, -02, -03, -05
RCM-SCLT
(gray, black, white, RAL9010 white) 70-184-01, -02, -03, -05
ACM-Tone
(gray, black, white, RAL9010 white) 70-181-01, -02, -03, -05
ACM-Level
(gray, black, white, RAL9010 white) 70-182-01, -02, -03, -05
