2-17VTG 400/400D • Installation and Operation
The following LCD display message is updated approximately every 38 seconds
starting with the timeout interval selected.
Time-out in:
00:18 minutes
After the timeout interval has has elapsed, the following LCD message is
displayed.
SCREEN SAVER
ACTIVE
The timeout timer is reset whenever any VTG button is pressed.
Screensaver Mode
The screensaver mode can be set to a blank (black) screen or the mode can be set
to cycle through all valid test patterns in 4-second intervals for the video type.
• Blank (default)
• Cycle
In blank screen mode, the sync remains active even while the video is muted.
Refer to the Test Pattern Chart in appendix A for the table of available test
patterns and their features.
Advanced Setup submenu (2 of 3)
The VTG’s LCD display features an adjustable contrast setting.
The internal board temperature of the VTG is also displayed in degrees Celcius
and degrees Fahrenheit.
LCD Display Contrast
• 000 through 063, select a setting while observing the LCD
Internal Temperature
• -67° to +257°F (-55° to +125°C)
Advanced Setup submenu (3 of 3)
The VTG can be reset to default settings from this submenu.
System Reset
• YES
• NO
Selecting “YES” displays a confirmation menu.
System Reset Confirm
• YES
• NO
Selecting “YES” resets the VTG to factory default settings.
A system reset does not affect any stored custom rates. Those rates are not
overwritten.
