2-19VTG 400/400D • Installation and Operation
Button Lock
Enabled!
O
Button Lock
Disabled!
O
SIGNAL
TYPE
TEST
PATTERN
Simultaneously press both buttons for
two seconds to enable button lock mode
Simultaneously press both buttons for
two seconds to disable button lock mode
Power
on
RES: VGA 640x480
FRQ: 31.50kHz 60.00Hz
PAT: Fine Crosshatch
SIG: Pink noise FRQ: N/A
LEV: -10 dBu 245mV
VTG 400
VIDEO TEST GENERATOR
60-564-01 Ver. 1.00
3 sec.
SIGNAL
TYPE
TEST
PATTERN
Button lock mode
