VTG 400/400D • Serial Communication3-4
Serial Communication
X14
= Audio tone frequency (1 - 121) [20 Hz to 20 kHz in 1/12 octave steps]
Audio Range
1 = 20 Hz
2 = 21.2 Hz
3 = 22.4 Hz
4 = 23.6 Hz
5 = 25 Hz
6 = 26.5 Hz
7 = 28 Hz
25 = 80 Hz
26 = 85 Hz
27 = 90 Hz
28 = 95 Hz
29 = 100 Hz
30 = 106 Hz
31 = 112 Hz
49 = 315 Hz
50 = 335 Hz
51 = 355 Hz
52 = 375 Hz
53 = 400 Hz
54 = 425 Hz
55 = 450 Hz
73 = 1.25 kHz
74 = 1.32 kHz
75 = 1.40 kHz
76 = 1.50 kHz
77 = 1.60 kHz
78 = 1.70 kHz
79 = 1.80 kHz
8 = 30 Hz
9 = 31.5 Hz
10 = 33.5 Hz
11 = 35.5 Hz
12 = 37.5 Hz
13 = 40 Hz
14 = 42.5 Hz
32 = 118 Hz
33 = 125 Hz
34 = 132 Hz
35 = 140 Hz
36 = 150 Hz
37 = 160 Hz
38 = 170 Hz
56 = 475 Hz
57 = 500 Hz
58 = 530 Hz
59 = 560 Hz
60 = 600 Hz
61 = 630 Hz
62 = 670 Hz
80 = 1.90 kHz
81 = 2.00 kHz
82 = 2.12 kHz
83 = 2.24 kHz
84 = 2.36 kHz
85 = 2.50 kHz
86 = 2.65 kHz
15 = 45 Hz
16 = 47.5 Hz
17 = 50 Hz
18 = 53 Hz
39 = 180 Hz
40 = 190 Hz
41 = 200 Hz
42 = 212 Hz
63 = 710 Hz
64 = 750 Hz
65 = 800 Hz
66 = 850 Hz
87 = 2.80 kHz
88 = 3.00 kHz
89 = 3.15 kHz
90 = 3.35 kHz
19 = 56 Hz
20 = 60 Hz
21 = 63 Hz
22 = 67 Hz
23 = 71 Hz
24 = 75 Hz
43 = 224 Hz
44 = 236 Hz
45 = 250 Hz
46 = 265 Hz
47 = 280 Hz
48 = 300 Hz
67 = 900 Hz
68 = 950 Hz
69 = 1.0 kHz
70 = 1.06 kHz
71 = 1.12 kHz
72 = 1.18 kHz
91 = 3.55 kHz
92 = 3.75 kHz
93 = 4.00 kHz
94 = 4.25 kHz
95 = 4.50 kHz
96 = 4.75 kHz
97 = 5.00 kHz
98 = 5.30 kHz
99 = 5.60 kHz
100 = 6.00 kHz
101 = 6.30 kHz
102 = 6.70 kHz
103 = 7.10 kHz
104 = 7.50 kHz
105 = 8.00 kHz
106 = 8.50 kHz
107 = 9.00 kHz
108 = 9.50 kHz
109 = 10.00 kHz
110 = 10.60 kHz
111 = 11.20 kHz
112 = 11.80 kHz
113 = 12.50 kHz
114 = 13.20 kHz
115 = 14.00 kHz
116 = 15.00 kHz
117 = 16.00 kHz
118 = 17.00 kHz
119 = 18.00 kHz
120 = 19.00 kHz
121 = 20.00 kHz
Square wave test signal uses frequencies 1 through 97 only.
X15
= Audio sweep speed (1 through 15)
1 = 1 sec
2 = 2 sec
3 = 3 sec
4 = 4 sec
5 = 5 sec
6 = 6 sec
7 = 7 sec
8 = 8 sec
9 = 9 sec
10 = 10 sec
11 = 20 sec
12 = 30 sec
13 = 60 sec
14 = 90 sec
15 = 120 sec
X16
= Scope Trigger cursor horizontal position (relative to active area)
Measured from first active video pixel in one-pixel increments.
X17
= Scope Trigger cursor vertical position (relative to active area)
Measured from first line of active video in one-line increments.
X18
= Scope Trigger cursor horizontal position (relative to total area)
Measured from beginning of the horizontal sync pulse in one-pixel increments.
X19
= Scope Trigger cursor vertical position (relative to total area)
Measured from the first line of the vertical sync pulse in one-line increments.
X20
= Scope Trigger cursor shape (1 through 2)
1 = Crosshair (default)
2 = Single pixel
X21
= Quick Select Preset number (1 through 4)
X22
= Quick Select Preset type (1 through 3)
1 = video settings
2 = audio settings
3 = all settings
X23
= Color enable type (0 - 7)
1 = blue
0 = black
2 = green
3 = cyan
4 = red
5 = magenta
6 = yellow
7 = white
R = off
R = off
R = off
R = off
R = on
R = on
R = on
R = on
G = off
G = off
G = on
G = on
G = off
G = off
G = on
G = on
B = on
B = off
B = off
B = on
B = off
B = on
B = off
B = on
