BCSD-14/116 Digital Brushless AC Servo Drive system - Ref. 1809
1.1.2. FBM Servomotor
• FBM Servomotor Model Designation.
• Rated Value and Specification of FBM motors.
FBM - 10 D D A 1 2
(1)
FAGOR servo motor
(2)(3)(4)(5)(6)(7)
(1) Model (3) Voltage (6) Shaft End
Code Model Code Voltage Code Shaft End
FBM Medium type D 400 V AC 1
Straight without key (Standard)
2 Straight with key and tap
(2) Rated Output (4) Encoder (7) Option
Code Rated Output Code Encoder Code Option
10 1.0 kW D Absolute encoder: 131072P/R 2 Without brake
15 1.5 kW 4 With brake (DC 24 V)
20 2.0 kW (5) Designing Sequence
30 3.0 kW
Code Designing sequence
50 5.0 kW A....... Designing sequence A
B....... Designing sequence B
Servo Motor Model
FBM-10DDB FBM-15DDB FBM-20DDB FBM-30DDA FBM-50DDA
Rated Output Power (kW) 1.0 1.5 2.0 3.0 5.0
Rated Torque (N.m) 4.78 7.16 9.55 14.3 23.9
Instantaneous peak Torque (N.m) 14.3 21.5 28.7 43.0 71.6
Rated current (Arms) 3.0 4.3 5.7 8.5 15.0
Instantaneous Max. current (Arms) 9.0 12.9 17.2 26.4 45.0
Rated speed (r/min) 2000
Max. speed (r/min) 3000
Rotor moment of inertia (10
-4
Kg.m
2
) 13.2 (14.3) 18.4 (19.5) 23.5 (24.6) 41.3 (44.5) 65.7 (68.9)
Brake rated voltage DC 24 V ±10%
Brake rated power (W) 19.5 35
Brake holding torque (N.m) 12 40
Encoder Absolute encoder: 131072P/R
Insulation class F
Ambient temperature 0 to +40 ºC (no freezing)
Ambient humidity 20 to 80% RH (non-condensing)
Vibration 24.5 m/s
2
Enclosure Totally Enclosed, Self-cooled, IP65
