Fagor BCSD Series User Manual

BCSD-36/116 Digital Brushless AC Servo Drive system - Ref. 1809
3. WIRING
3.1. Main Circuit Wiring
Please observe the following instructions while wiring the main circuit.
CAUTION
• Do not bundle or run power and signal lines together in the same duct. Keep power and signal lines
separated by at least 300 mm.
• Use twisted-pair shielded wires or multi-core twisted-pair shielded wires for signal and encoder
feedback lines.
• The maximum length is 3 m for reference input lines and is 20 m for encoder feedback lines.
• Do not touch the power terminals for 5 minutes after turning power OFF because high voltage may
still remain in the servodrive.
3.1.1. Names and Functions of Main Circuit Terminals
Terminal
Symbol
Name
Main Circuit
Voltage (V)
Drive type
BCSD
Functions
L1, L2, L3
Main circuit
power supply
input terminal
220 08A-10A
Three-phase 200~230 V AC
+10% ~ -15% (50/60 Hz)
400 10D-50D
Three-phase 380~480 V AC
+10% ~ -15% (50/60 Hz)
U, V, W
Servomotor
connection
terminals
- Connect to the servomotor.
L1C, L2C
Control circuit
power supply
input terminal
220 08A-10A
Single-phase 200~230 V AC
+10% ~ -15% (50/60 Hz)
24V, GND 400 10D-50D 24 V DC +10% ~ -15%
Ground terminals -
Connects to the power supply ground
terminals and servomotor ground terminal.
B1, B2, B3
Regenerative
resistor
connection
terminal
220/400
08A-10A
10D-50D
Using an internal regenerative resistor,
please short B2 and B3.
+1, +2
DC reactor for
harmonic
suppression
terminal
220/400
08A-10A
10D-50D
Normally short 1 and 2.
If a counter measure against power supply
harmonic waves is needed, connect a DC
reactor between 1 and 2.
-
Main circuit
minus terminal
220/400
08A-10A
10D-50D
Normally not connected.
