BCSD-10/116 Digital Brushless AC Servo Drive system - Ref. 1809
1.1. Servo motor
1.1.1. FBS Servomotor
• FBS Servomotor Model Designation.
FBS - 10 A D B 1 2
(1)
FAGOR servo motor
(2)(3)(4)(5)(6)(7)
(1) Model (4) Encoder (7) Option
Code Model Code Encoder Code Option
FBS Small type D Absolute encoder: 131072P/R 2 Without brake
4 With brake (DC 24 V)
(2) Rated Output (5) Designing Sequence
Code Rated Output Code Designing sequence
08 750 W B Designing sequence
10 1.0 kW
(3) Voltage (6) Shaft End
Code Voltage Code Shaft End
A 220 V AC 1 Straight without key (Standard)
2 Straight with key and tap
