Reviewing ISO Track Locations
Review the Magnetic Encoding module, which encodes onto Tracks in accordance with an
ISO 7811-2 Magnetic Stripe. Refer to the diagram (below) for Track locations. (Note: All
standard Persona C25 Card Printers are capable of printing onto oversized cards; however,
a special version of the Printer is required to encode the Magnetic Stripe of oversized cards.)
TRACK1 0.110"
TRACK2 0.110"
TRACK3 0.110"
0.130"
0.140"
0.223" 0.353" 0.493"
Persona® C25 Card Printer User Guide (Rev. 4.0)
116
