Reviewing the Printer Timing
Interval Description Minimum
Value
Typical
Value
Tdsu Data setup time 0.5 µs
Tstr
_____
Data strobe width
1 µs
Tack
______
Acknlg pulse width 3.75 µs
Tdh Data hold time 0.5 µs
Tsb
_
____
Busy delay time from data strobe
0.5 µs (max.)
