Technical specifications
4812164601_C.pdf 2023-01-05
Compaction data
(CC1300C VI - CC1400C VI)
Compaction data
(CC1300C VI - CC1400C VI)
Static linear load (front/rear)Static linear load (front/rear)
CC1300C VI 14,5 kg/cm 80 pliCC1300C VI 14,5 kg/cm 80 pli
CC1400C VI 15,1 kg/cm 85 pliCC1400C VI 15,1 kg/cm 85 pli
AmplitudeAmplitude
- Single 0.5 mm 0.0197 in.- Single 0.5 mm 0.0197 in.
- Double (High/Low) 0.2/0.5 mm 0.0079/0.0197 in.- Double (High/Low) 0.2/0.5 mm 0.0079/0.0197 in.
Vibration frequencyVibration frequency
- Single amplitude 54/49 Hz 3.240/2.940 vpm- Single amplitude 54/49 Hz 3.240/2.940 vpm
- Dual amplitudes 61/54 Hz 3.660/3.240 vpm- Dual amplitudes 61/54 Hz 3.660/3.240 vpm
Centrifugal forceCentrifugal force
CC1300C VI (Single amplitude)CC1300C VI (Single amplitude)
- V2203-M 38/31 kN 8.543/6.969 lb- V2203-M 38/31 kN 8.543/6.969 lb
- V2403-CR 38/31 kN 8.543/6.969 lb- V2403-CR 38/31 kN 8.543/6.969 lb
CC1300C VI (Dual amplitudes)CC1300C VI (Dual amplitudes)
- V2203-M 38/21 kN 8.543/4.721 lb- V2203-M 38/21 kN 8.543/4.721 lb
- V2403-CR 38/21 kN 8.543/4.721 lb- V2403-CR 38/21 kN 8.543/4.721 lb
CC1400C VI (Single amplitude)CC1400C VI (Single amplitude)
- V2203-M 43/35 kN 9.667/7.868 lb- V2203-M 43/35 kN 9.667/7.868 lb
- V2403-CR 43/35 kN 9.667/7.868 lb- V2403-CR 43/35 kN 9.667/7.868 lb
CC1400C VI (Dual amplitudes)CC1400C VI (Dual amplitudes)
- V2203-M 43/22 kN 9.667/4.946 lb- V2203-M 43/22 kN 9.667/4.946 lb
- V2403-CR 43/22 kN 9.667/4.946 lb- V2403-CR 43/22 kN 9.667/4.946 lb
22
