Machine description
4812164601_C.pdf2023-01-05
1
Fig. Submenu, Regeneration
1. Activation of regeneration when this is
possible
Submenu - Regeneration
(D1803 (Tier 4f / Stage V) /
V2403-CR (Tier 4f / Stage V))
Regeneration is activated using the button (1) on the
right-hand side of the display.
Parked regeneration requires the following conditions
to be met:
- FNR/selector lever in neutral position
- Parking brake activated
- Engine temp >65°C (Tier 4f engine)
- Engine temp >50°C (Stage V engine)
- Engine speed in mode LOW
1
6
5
Fig. Regeneration required
5. Red warning symbol (Serious fault)
6. Yellow warning symbol
(Less serious fault)
Soot
1. When the symbol (1) is lit, regeneration needs to be
performed but parameters for automatic regeneration
are not met.
Level 1
If the symbol (1) on the display is lit with a solid light,
an Automatic regeneration is required.
For Stage V engines you can choose to perform a
Parked regeneration in this mode, provided that the
conditions for regeneration are met.
A Yellow warning symbol (6) lights with a solid light.
No error codes are shown on this level.
Click “OK” to confirm the information and return to the
previous menu.
Level 2
If the symbol (1) on the display flashes an Automatic
regeneration is required.
You can also choose to perform a Parked
regeneration, provided that the conditions for
regeneration are met.
A Yellow warning symbol (6) lights with a solid light
and error codes can be launched with this.
Click “OK” to confirm the information and return to the
previous menu.
