Operation
4812164601_C.pdf 2023-01-05
Switching off
32
1
2
31
22
9
Fig. Instrument panel
1. Ignition key
2. Throttle control (D1703 / V2203-M-E3B)
9. Instrument cover
22. Panel for warning lamps
31. Parking brake
32. Engine speed selector
(D1803/V2403-CR-E4B/V2403-CR-E5B)
Activate the parking brake (31).
D1703 / V2203-M-E3B (Stage IIIA)
Turn the engine speed control (2) back to idling.
D1803 / V2403-CR-E4B (Tier 4f) /
V2403-CR-E5B (Stage V)
Press the LED button (32) so it is set to LOW mode
(left LED lit).
Allow the engine to idle for a few minutes to cool down.
Check instruments and warning lamps to see if any
faults are indicated. Switch off all lights and other
electrical functions.
Turn the ignition key (1) to the left to the switched off
position. At the end of the shift, fold over the
instrument cover (9) and lock.
80
