Fayat DYNAPAC CC1400C - Foldable ROPS - Bolts; Hydraulic System

Technical specifications
4812164601_C.pdf2023-01-05
ROPS-bolts which are to be torque tightened
must be dry.
ROPS-bolts which are to be torque tightened
must be dry.
Foldable ROPS - bolts
CC1100/C VI - CC1200/C VICC1100/C VI - CC1200/C VI
Bolt dimensions : M16Bolt dimensions : M16
Strength class : 8.8Strength class : 8.8
Tightening torque : 190 Nm (Zinc plating)Tightening torque : 190 Nm (Zinc plating)
CC1300/C VI - CC1400/C VICC1300/C VI - CC1400/C VI
Bolt dimensions : M16Bolt dimensions : M16
Strength class : 10.9Strength class : 10.9
Tightening torque : 305 Nm (Zinc flake)Tightening torque : 305 Nm (Zinc flake)
Always replace a lost bolt with an original bolt.
Hydraulic system
Opening pressure
(Absolute pressure)
MPaOpening pressure
(Absolute pressure)
MPa
CC1100C VI - CC1200C VI CC1300C VI - CC1400C VICC1100C VI - CC1200C VI CC1300C VI - CC1400C VI
Drive system 35,0 35.0Drive system 35,0 35.0
Supply / Charge system 2.0 2,2Supply / Charge system 2.0 2,2
Vibration system 21,0 22.8Vibration system 21,0 22.8
Control systems 18,0 18.0Control systems 18,0 18.0
Brake release 1.2 1.8Brake release 1.2 1.8
25
