Machine description
4812164601_C.pdf 2023-01-05
Working mode, Vibration
2
1
Fig. Working mode, Vibration both
drums, AVC selected
The different working modes are selected with the help
of the working mode button on the panel.
1. Optional asphalt temperature meter (see the
chapter asphalt temperature meter)
Symbols are shown in the menu Working mode,
vibration for forward and rear drums.
2. Compaction status (off/on) on front/rear drum
Press one of the buttons (7) on the far right of the
panel. The side menu (8) will then appear on the
display.
Fig. Working mode, Vibration both drums,
AVC selected
78
9
7
The lowermost button (7) activates AVC mode
(Automatic Vibration Control), activation lights the AVC
symbol (9).
Press the uppermost button (7) and the submenu is
displayed.
The lowermost button (7) on the panel is pressed,
AVC (9) is activated and the symbol in the bottom right
of the display lights.
Fig. Working mode - Vibration Off
4
56
