Operation
4812164601_C.pdf2023-01-05
1
Fig. Operator platform
1. Flow divider switch
Flow divider (Optional)
The switch on the floor (to the left) must be press
down to activate the flow divider.
The flow divider is enabled as long
as the switch is actuated.
Remove your foot from the switch
to disable the flow divider.
Starting
Starting the engine
32
1
2
3
6
29
31
Fig. Control panel
1. Ignition key
2. Throttle control (D1703/V2203-M-E3B)
3. Emergency stop
6. Forward/Reverse lever
29. Glow lamp
31. Parking brake
32. Engine speed selector
(D1803/V2403-CR-E4B/V2403-CR-E5B)
The operator must remain seated when starting.The operator must remain seated when starting.
Make sure that the emergency stop (3) is pulled out
and the parking brake (31) is activated.
Set the forward/reverse lever (6) in neutral. The
engine can only be started when the lever is in neutral.
Do not run the starter motor for too long. If the
engine does not start, wait a minute or so before
trying again.
Do not run the starter motor for too long. If the
engine does not start, wait a minute or so before
trying again.
D1703 / V2203-M-E3B (Stage IIIA)
At high ambient temperatures, set the engine speed
control (2) to the position just over idling.
On cold start, set the engine speed control to medium
revs. Preheating: Turn the ignition key to position II.
When the glow lamp (29) goes out: Turn the ignition
key (1) to the right. As soon as the engine starts,
release the ignition key and reduce the engine speed
to just over idling (because high revs can damage a
cold engine). As soon as the engine is running
smoothly, reduce the revs down to idling.
73
