Operation
4812164601_C.pdf 2023-01-05
The engine can only be started with the parking
brake (6) activated.
The engine can only be started with the parking
brake (6) activated.
6
9
Fig. Instrument panel
6. Parking brake
9. Brake warning lamp
Reserve brake - Control
Drive slowly fowards/backwards and press down the
parking brake button (6) to activate it.
The roller must now stop immediately.
Instruments and lamps - Checking
3
22
12
1
Fig. Instrument panel
1. Ignition key
3. Emergency stop
12. Sprinkler activation button
22. Display
Make sure that the emergency stop button is
pulled out and the parking brake is activated.
Make sure that the emergency stop button is
pulled out and the parking brake is activated.
Turn the ignition key (1) to position 2.
Check that the warning symbols are shown
on the display (22).
Activate the front sprinkler button (12) to the operating
position, and check that the system works.
70
