FENDT 926 Vario User Manual

87
OPERATION
19.3 Mechanical side locks
Operation_Pic_number:1
The lower links are locked using the left and right
levers (A).
Mounted implement rigid.
● Move lever up.
Mounted implement with lateral movement.
● Move lever down.
Fig.192
19.4 Top link
Operation_Pic_number:1
● Adjust length by turning handle (A).
Both threads must be of equal length; securing
clamp must clip over peg (B).
Attaching at tractor
Operation_Pic_number:1
Can be fastened to three bores (for better
implement adaptation and for increasing lifting
force).
Increased lifting power, reduced lifting
height.
● Fit top link into the upper hole.
Reduced lifting power, increased lifting
height.
● Fit top link in low position.
Fig.193
Fig.194

FENDT 926 Vario Specifications

General

Engine Power	260 hp
Transmission	Vario continuously variable transmission
Fuel Tank Capacity	500 liters
Weight	10, 500 kg
Engine type	6-cylinder turbocharged
Rated engine speed	2100 rpm
Displacement	7.5 liters
Number of cylinders	6
Maximum speed	50 km/h
Tire Options	Multiple options available
