TRANSPORT AND INSTALLATION
4.9
4.10
04-Rimozione imballo (ZM-ZMTE)
P
B
11) Correctly position the support feet of the arms of the machine with the proper pin, putting it in a central position to
give stability when the machine is parked.
12) Attach the three-point coupling of the machine. Lift the arc attaching it using a belt (as indicated in the gure)
or a chain to which the hook is xed in one of the two three-point coupling holes.
