49
Rev. 5.1
ZMT-ZMTE
TRANSPORT AND INSTALLATION
4.11
4.12
04-Rimozione imballo (ZM-ZMTE)
13) Move the three-point coupling arc towards the machine and in particular to the end part of the parallel arms.
Keeping the arc raised, position it near the arm attachments so that the pin can be inserted between the
attachment and the arm set. Insert and x the appropriate pin with the relative nut.
