6Functions
72 Festo – GDCP-CMMP-M0-FW-E N – 1304NH
Overflow limitation activated
The numerical overflow limitation limits the voltage values U calculated corresponding to the scaling to
the range +10 V … -10 V.
Overflow limitation not activated
In c ase of overflow of the range limit +10 V, the output voltage jumps to (–10 V +Δ U).
In c ase of overflow of the range limit -10 V, the output voltage jumps ( + 10 V -ΔU).
6.7.8 Supported encoder systems
The following encoder systems are supported by the motor controllerCMMP-AS-...-M0:
Type
Remark Protocol Interface
Heidenhain Endat encoder
ROC 400
ECI 1100/1300
ECN
100/400/1100/1300
Single-turn absolute encoder wit h/
without analogue signal
EnDat 2.1 ( 01/21)
EnDat 2.2 ( 22)
[X2B]
ROQ 400
EQI 1100/1300
EQN
100/400/1100/1300
Multi-turn absolute encoder with/
without analogue signal
EnDat 2.1 ( 01/21)
EnDat 2.2 ( 22)
[X2B]
LC 100/400 Absolute length measurement
equipment
EnDat 2.1 ( 01)
EnDat 2.2 ( 22)
[X2B]
Stegmann HIPERFACE Encoder
SCS60/70 S CM60/70 Single-/multi-turn encoder with
analogue inc remental signals.
Sine/cosine periods 512. Max.
revolutions multi-turn: + /- 2048 R.
HIPERFACE [X2B]
SRS50/60/64 SCKxx
SRM50/60/64 SCLxx
Single-/multi-turn encoder with
analogue inc remental signals.
Sine/cosine periods 1024. Max.
revolutions multi-turn: + /- 2048 R
HIPERFACE [X2B]
SKS36 SKM36 Single-/multi-turn encoder with
analogue inc remental signals.
Sine/cosine periods 128. Max.
revolutions multi-turn: + /- 2048 R
HIPERFACE [X2B]
SE K37/52 S EL37/52 Single-/multi-turn encoder with
analogue inc remental signals.
Sine/cosine periods 16. Max.
revolutions multi-turn: + /- 2048 R
HIPERFACE [X2B]
