Sequence of configuration entries
CAUTION
You must always configure inputs before
outputs.
The number of inputs/outputs (rounded up to
full bytes) must correspond to the equipment
fitted on the terminal. No additional inputs or
outputs may be configured as reserves.
PLEASE NOTE
Information on using the GSD files and type
files can be found in:
•
the file Readme on the diskette supplied
•
the manual for your configuration program
Copy the type files or the GSD files supplied into
the appropriate directory in your configuration
program. The following screen masks show
different examples.
• Station selection
• Configuration.
