Festo FB13 - Examples

Examples
Example 1
Valve terminal with 60 inputs and 26 valve coils.
Configuration:
Configured I/Os Number of
bytes
Consistency Identifier
60 inputs 8 (DI) 1 byte 023
32 outputs 4 (DO) 1 byte 035
Example 2
Valve terminal with 44 inputs, 16 valve coils, 8
electrical outputs.
Configuration:
Configured I/Os Number of bytes Consistency Identifier
44 inputs 6 (DI) 1 byte 021
16 valve coils
8 outputs
3 (DO) 1 byte 034
