1.1 SYSTEM SUMMARY
System structure
Festo offers a solution to automation problems at
machine level in the form of the valve terminal.
Valve terminals of type 03/05 are constructed on
a modular basis and permit combinations of
pneumatic and electric modules, such as the
following:
Valve terminal type 03:
MIDI/MAXI valves and
electric modules
further slaves
Valve terminal type 03:
only MAXI valves
Valve terminal type 05:
ISO valves and
electric modules
PROFIBUS-DP
Industrial PC
Controller
- Simatic S5/S7
- Bosch
- etc.
Fig. 1/1: System summary and possible variants of valve terminals
VIFB13 - 03/05 1. User instructions
9701 NH 1-3
