4.1 BASIC PRINCIPLES OF CONFIGURATION AND ADDRESSING
General
Before commissioning or programming, the user
should compile a configuration list for the
connected field bus slaves. On the basis of this
list he can:
• make a comparison between the ACTUAL
and NOMINAL configurations in order to
recognise connection errors;
• access these specifications during the syntax
check of a program, in order to avoid
addressing errors.
The valve terminal must be configured very
accurately, since different configuration
specifications may be necessary for each termi-
nal due to the modular structure. Observe here
also the specifications in the following sections.
PLEASE NOTE
You can display the configuration data of the
valve terminal via the LEDs "POWER V" and
"BUS ERROR" (see chapter 5.3).
