Commissioning tips
PLEASE NOTE
You must observe the following points in order
to guarantee reliable operation of your applica-
tions with the Festo valve terminal.
• Insert the IM 308-B, IM 308-C, CP xx etc.
into the correct location on your automation
device.
• The ET200 location number bears no rela-
tionship to the physical arrangement of the
input/output modules.
• Observe any limitations in the number of
digital inputs/outputs e.g. CPU 941. max. 512.
• The station number set does not correspond
to the configured periphery address.
• When configuring the outputs (e.g. 8DO 8DO
8DO), note that the number and type of
pneumatic sub-bases is decisive, and not
the number of valves fitted.
• The periphery addresses of automation de-
vice components must not be the same as
the configured periphery addresses.
• The number of input bits always increases by
4 (= status bits).
• Reserved addresses for future requirements
are not permitted.
• Switch on terminating resistor on both sides
VIFB13 - 03/05 4. Commissioning
