Description of the functions
The node takes control of the following functions:
• connection of the terminal to the bus control-
ler and to further slaves via the bus interface
• adaption to the field bus baud rate and
protocol of the control system
• control of the terminal periphery.
Work air
Fig. 1/8: Function summary of valve terminal type 03/05
Incoming field bus
Continuing field bus
Node
VIFB13 - 03/05 1. User instructions
9701 NH 1-11
