4.3 GENERAL DP-MASTER
The Festo valve terminal of types 03-05 can be
controlled by any PLC, PC or industrial PC with
a PROFIBUS-DP module as per EN 50170
(DIN 19245).
Status bits
The valve terminal always makes 4 status bits
(= inputs) available for diagnostic purposes, if the
valve terminal is fitted with at least one input
module (4 or 8-inputs).
PLEASE NOTE
•
The 4 status bits always increase the
number of inputs to be configured by 4.
•
Valve terminals without inputs do not have
any status bits.
Please refer to chapter 5 ”Diagnostics/error
treatment” for the function and position of the
status bits.
VIFB13 - 03/05 4. Commissioning
9701 NH 4-45
