Example 2
Addressing a valve terminal with 44 inputs (+ 4
status bits), 3 single solenoid valves/5 double
solenoid valves and 16 digital outputs.
Configuration: 8DI Periphery address 52
8DI Periphery address 53
8DI Periphery address 54
8DI Periphery address 55
8DI Periphery address 56
8DI Periphery address 57
8DO Periphery address 52
8DO Periphery address 53
8DO Periphery address 54
8DO Periphery address 55
0
1
2
3
4
5
6
7
9
8
11
10
12
13
*
14
15
16
17
18
19
A4
20
21
22
23
A4
24
25
26
27
A4
28
29
30
31
A4
9
8
11
10
13
12
15
14
E8
1
0
3
2
5
4
7
6
E8
17
16
19
18
21
20
23
22
E8
25
24
27
26
29
28
31
30
E8
33
32
35
34
37
36
39
38
E8E4
40
41
42
43
Program
:
:U I53.0 "Input I0.08 (2nd. input module, 1st. input)
:= O52.5 "Output O0.05 (4th. valve, left-hand coil)
:
:U I55.4 "Input I1.12 (4th. input module, 5th. input)
:= O53.0 "Output O0.08 (6th. valve, right-hand coil)
:= O54.6 "Output O1.06 (2nd. output module, 3rd. output)
*unused
I57.3 - I57.0
I56.7 - I56.0
I55.7 - I55.0 I54.7 - I54.0 I53.7 - I53.0
I52.7 - I52.0
O55.7 - O55.4
O54.7 - O54.4
O55.3 - O55.0
O54.3 - O54.0
O52.0
O52.4 O52.5* O52.6 O52.7 O53.0 O53.1
O52.1 O52.2 O52.3 O53.6 O53.7
O53.2 O53.3 O53.4 O53.5
Fig. 4/16: Addressing example 2
VIFB13 - 03/05 4. Commissioning
4-44
