Summary of possible station addresses/
station numbers
PLEASE NOTE
Station addresses/station numbers may be as-
signed only once per field bus module/
PROFIBUS-DP interface.
Observe also any limitations as regards the
assignment of station numbers via the DP
master.
Recommendation
Assign the station addresses/station numbers in
ascending order and adapter them to the
machine structure of the system.
Permitted station numbers 0;...; 125
Fig. 3/6: Permitted station numbers
Proceed as follows:
1. Switch off the power supply.
2. Assign a non-reserved field bus address to
the valve terminal.
3. Use a screwdriver to set the arrow of the rele-
vant address selector switch or DIL switch 1
to the units, tens or hundreds figure of the
desired station number.
VIFB13 - 03/05 3. Installation
3-12
9701 NH
