Send parametrizing data
The parametrizing data are transferred from the
DP-master to the valve terminal with the function
Set_Prm .
Octet 1: Station status
Bit Meaning Explanation
0
- Reserved
1
-
2 -
3 WD_On Response monitoring of valve terminal on/off:
log. "0": off
log. "1": on
4
Freeze_Req Logic "1": FREEZE activated
5
Sync_Req Logic "1": SYNC activated
6
Unlock_Req Bit 7 Bit 6 Explanation
7
Lock_Req 00min T
SDR
+ valve terminal
parameter
may be overwritten
0 1 Valve terminal released for other
masters
1 0 Valve terminal blocked for other
masters
1 1 Valve terminal released for other
masters
Octet 2 and 3: WD_Fact_1
WD_Fact_2
Bit Meaning Explanation
Range 1 - 255:
The response monitoring time of the valve
terminal is transferred with these two octets:
T
WD
[s] = 10ms * WD_Fact_1 * WD_Fact_2
VIFB13 - 03/05 4. Commissioning
9701 NH 4-47
