Parameter summary (Chk_Cfg):
Octet 1-n:
Identifier bytes
Permitted identifiers for Festo
valve terminals
Example:
Configuring a valve terminal with up to 28 in-
puts and 24 outputs.
Station no.: 20
Configuration: Function: Chk_Cfg
Octet 1: 19
D
Octet 2: 34
D
Request diagnostic information
The diagnostic data are requested from the valve
terminal with the function Slave_Diag.
The description of this function is to be found in
Chapter 5, section "Diagnosis via PROFIBUS-
DP".
Number of
I/Os
Valve terminal I/Os
Inputs* Outputs
Decimal Hex. Decimal Hex.
up to 8
016 010 032 020
up to 16
017 011 033 021
up to 24
018 012 034 022
up to 32
019 013 035 023
up to 40
020 014 036 024
up to 48
021 015 037 025
up to 56
022 016 038 026
up to 64
023 017 039 027
up to 72
024 018 040 028
up to 80
025 019 041 029
up to 88
026 01A - -
up to 96
027 01B - -
up to 104
028 01C - -
VIFB13 - 03/05 4. Commissioning
4-50
9701 NH
