PLEASE NOTE
You can configure max. 7 identifiers. The indi-
vidual identifiers must correspond to the exist-
ing equipment fitted on the valve terminal.
•
Additional inputs/outputs as reserves are
not permitted.
•
If identifiers for certain components are not
used, you should enter the next following
identifiers.
Enter the identifiers in the following sequence:
1. digital inputs of the valve terminal (incl. 4
status bits)
2. digital outputs of the valve terminal (valves
and electrical outputs)
3. AS-i inputs
4. AS-i outputs
5. analogue inputs
6. analogue outputs
7. AS-i parametrizing field
VIFB13 - 03/05 4. Commissioning
9701 NH 4-57
