PLEASE NOTE
This manual includes a diskette with the
device master files and the type files. The
referenced file names refer to version V1.4.
Explanations can be found on the file
"Readme".
All information on the pneumatic modules is
to be found in the Pneumatics Manual
P.BE-MIDI/MAXI-03-GB or P.BE-ISO-05-GB.
Abbreviation Meaning
Terminal or
Valve terminal
Valve terminal type 03
(MIDI/MAXI) or
type 05 (ISO)
with/without electric I/Os
Node Field bus node
Valve-sub base
S sub-base
D sub-base
ISO sub-base
Pneumatic sub-base for valves
For two single valves
type 03 (MIDI/MAXI)
For two double solenoid valves
or mid-position valves
type 03 (MIDI/MAXI)
Sub-base for 4, 8 or 12
ISO valves type 05
(as per ISO 5599/I, size 1 or 2)
I
O
I/O
Input
Output
Input and/or output
P module Pneumatic module in general
I/O module Module with digital
inputs/outputs in general
(input/output modules)
PLC Programmable logic controller;
or simply controller
Fig. 0/1: Abbreviations
