5.6 DIAGNOSIS VIA PROFIBUS-DP (GENERAL DP-MASTER)
General
PLEASE NOTE
Evaluation of the device-related diagnostic in-
formation 4..7 (octet 11..14) is only sensible in
conjunction with an AS-i master integrated in
the valve terminal.
The identifer or channel-related diagnosis
listed in EN 50170 (DIN 19245), part 3 is not
supported.
Valve terminal types 03-05 make the following
diagnostic information available as per DIN
19245, part 3.
Octet Meaning
1 Station status_1
2 Station status_2
3 Station status_3
4 Diag.master_Add
5 Ident_Number
6 Ident_Number
7 Header device-related diagnosis (Ext_Diag_Data)
8 Device-related diagnosis 1 - Error summary
9 Device-related diagnosis 2 - Bit no. error at output
10 Device-related diagnosis 3 - Byte no. error at output
11 Device-related diagnosis 4 - Error bits AS-i bus slaves 0-7
12 Device-related diagnosis 5 - Error bits AS-i bus slaves 8-15
13 Device-related diagnosis 6 - Error bits AS-i bus slaves 16-23
14 Device-related diagnosis 7 - Error bits AS-i bus slaves 24-31
