Festo FB13 - Page 165

Octet 9: Device-related diagnosis 2
Explanation
The valve terminal enters the bit number
of the short circuited or overloaded electrical
output in this octet.
Octet 10: Device-related diagnosis 3
Explanation
The valve terminal enters the byte number
of the short circuited or overloaded electrical
output in this octet.
Octet 11-14: Device-related diagnosis 4-7
Explanation
Each set bit ("logic 1") of this octet
represents an incorrect AS-i bus slave.
See manual for AS-i master
11 Device-related diagnosis 4 - error bits AS-i bus slaves 0-7
12 Device-related diagnosis 5 - error bits AS-i bus slaves 8-15
13 Device-related diagnosis 6 - error bits AS-i bus slaves 16-23
14 Device-related diagnosis 7 - error bits AS-i bus slaves 24-31
VIFB13 - 03/05 5. Diagnosis/error treatment
5-26
9701 NH
