Earth cable connection pin 4 designed for 12 A
Connecting cable for
potential compensation of
earth connections
10 A
0 V
3.15 A
DC 24V
± 10%
Connected adapter cable
Operating voltage connection
AC
EMERGENCY
STOP
External fuses
Fuse for valves (4 A)
24 V
Fig. 3/15: Example – connecting a common 24 V supply
and both earth cables (type 05)
VIFB13 - 03/05 3. Installation
3-28
9701 NH
