Four transistor outputs are available for the user
on the output modules of the valve terminal. The
outputs have positive logic (PNP outputs).
Output module (4 outputs)
Fig. 3/21: Digital output modules (4 outputs)
Socket
with one
digital
output
Yellow LED per output
Red LED per output
VIFB13 - 03/05 3. Installation
3-36
