Calculating the configuration data
Before configuring, calculate the exact number of
available inputs/outputs. A modular valve termi-
nal consists of a varying number of I/Os,
depending on the type ordered.
PLEASE NOTE
The terminal provides four status bits for
diagnosis.
These are always assigned automatically
within the terminal there are input modules.
The status bits occupy four input addresses.
The following table specifies the I/Os required
per module for the configuration.
Module type Number of assigned I/Os*)
Single-type valve sub-base (type 03)
Double-type valve sub-base (type 05)
ISO sub-base modules (type 05)
- 4 valve locations
- 8 valve locations
- 12 valve locations
4-output module (4 digital outputs)
4-input module (4 digital inputs)
8-input module (8 digital inputs)
Status bits**)
2 outputs
4 outputs
8 outputs
16 outputs
24 outputs
4 outputs
4 inputs
8 inputs
4 inputs
*) The I/Os are assigned automatically in the terminal, irrespective of whether
an input/output is actually used.
**) The status bits are assigned automatically in the terminal when there are
input modules
Fig. 4/1: Number of assigned I/Os per module
VIFB13 - 03/05 4. Commissioning
9701 NH 4-7
