B.1 Technical specifications
Technical specifications Type SPC11-...-...-ASI
Dimensions (plug exit on top,
without cable, incl. fastening
bracket)
–Height
–Width
–Depth
Approx. 43 mm
Approx. 118.4 mm
Approx. 80 mm
Weight Approx. 400 g
Temperature range – Operating temperature
–storage/transport
0 ... + 50 °C
- 20 ... + 70 °C
Relative humidity 95%, non- condensing
Protection class as per EN 60529; plug connector inserted or
provided with protective cap
IP65
Protection against electric shock
as per EN 60204-1/IEC 204
(protection against direct and
indirect contact)
By connection to a PE LV power
unit (Protected Extra Low
Volt age)
AS-Interface bus connection –Voltagerange
– Residual ripple
– Max. current consumption
26.5 ... 31.6 V DC
≤ 20 mVpp
Approx. 40 mA
AS-Interface data –Profile ID code = 4
IO code = 7
H
Power supply –Voltage
– Permitted fluctuations in
voltage
– Residual ripple
– Current consumption incl.
Valve
Type SPC11-POT-...
Type SPC11-AIF-MTS
– Current consumption
without valve
Type SPC11-POT-...
Type SPC11-AIF-MTS
24 V DC
- 10 ... + 25 %
Max. 6 %
1.2 A
1.3 A
Approx. 70 mA
Approx. 170 mA
