3. Installation
3-4
Festo P.BE-SPC11-SYS-ASI -EN en 0203NH
3.2 Notes on installing the pneumatic components
Please note
Observe the following instructions on installing the pneu-
matic components. Only then can you guarantee faultless
operation.
12345
6
789
1 ... 9 Notes on install a ti on s ee the following pages
Fig. 3/1: Overview of pneumatic installation
