5. Diagnosis and error treatment
5-4
Festo P.BE-SPC11-SYS-ASI -EN en 0203NH
LED display on the SPC11
ASI LED
(green)
Fault LED
(red)
Meaning
on off AS-Interface voltage applied, no fault
off off No AS-Interface voltage on the bus
flashes on AS-Interface address not set (= 0)
on flashes The slave is in the reset status (AS-Interface communication reset)
flashes flashes Operation in accordance with slave profile 7.4:
Fault on the axis system (fault number see section 5.1.1 )
on on Bus communic a t ion f ailed (watchdog expired)
5.1.1 Fault display on the SPC11
Fault no. Operating status Eliminating faults
Measuring system not connected or measur-
ing system cable fracture.
S Connect the measuring system or
check the cable.
Incorrect direction of movement ascertained
during identification; tubing is incorrectly
connected.
S Correct the tubing of the propor-
tional directional control valve.
Offset fault in the static identification:
The proportional directional control valve is
faulty or there is an external fluctuating
force on the slide during identification
travel.
S R eplace t he propor tional direc-
tional control valve or use the
constant external force during
identification travel.
No movement during sta tic identification. S Check the compressed air supply
and the tubing.
Overswing fault during dynamic identifica-
tion due to incorrect amplification stage,
cushioning stage or system parameter.
S Check and correct the amplifica-
tion stage, cushioning stage and
system parameter.
