Festo Soft Stop SPC11 Series User Manual

3. Installation
3-20
Festo P.BE-SPC11-SYS-ASI -EN en 0203NH
3.3.1 Connecting elements of the SPC11
The diagram below shows the connecting elements of the
SPC11, using the SPC11-POT-TLF as an example.
1 Measuring sys-
tem connection
(here for type
MLO-POT-...-TLF)
2 Earth/ground
connection
3 24 V DC:
Operating voltage
connection
4 Valve:
Valve connection
5 Bus:
AS-Interface bus
connection
1
2
34
5
Fig. 3/9: Connecting elements of the SPC11
