4. Commissioning
4-16
Festo P.BE-SPC11-SYS-ASI -EN en 0203NH
The permitted values of the parameters for the drive you are
using can be found in the appropriate axis-specific supple-
ment. The currently set values will be shown briefly when the
operating voltage is switched on (see also Fig. 4/2).
If the SPC11 is in the status as at delivery:
When the operating vol tage is switched on the SPC11 waits
for the amplification stage (A) to be entered.
S In this case, set the parameters as described in section
4.2.
If the parameters have already been set:
When the operating vol tage is switched on the SPC11 show s
briefly the set parameters one after the other, so that they can
be checked. The SPC11 then indic ates readiness to carry out
the teach procedure (t flashes).
(The t flashes.)
The teach procedure can now be started (see sections 4.3.2).
